RFID Tag Smartrac Miniweb Impinj M730
The RFID Miniweb Impinj M730 tag from Smartrac has been specifically designed for application in the fashion, automotive, and logistics sectors. Its structure and composition are optimal for integration into the supply chain, contributing to improved inventory management and increased precision and automation in processes.
Equipped with the advanced Impinj M730 chip, this RFID tag features a 128-bit EPC memory and a 96-bit TID memory. Its exceptional performance ensures a higher number of reads and writes compared to other tags in its competition, surpassing their capabilities.
This device operates in the UHF frequency range from 860 to 960 MHz, and its inlay features dimensions of 45 x 18 mm, giving it a rectangular configuration. It performs smoothly on various surfaces, and depending on the conditions and environment in which the tag is used, it can achieve a reading range of up to 14 meters.
Just like all Avery Dennison’s RFID products, this tag is manufactured following rigorous industry quality standards. It complies with the international standards of quality and performance ISO/IEC 18000-63, EPC Gen2 V2, ensuring its optimal performance even in challenging environments.
Product Code:
Dry Inlay: 3007865 / IL-603909
Wet Inlay: 3007866 / IL-600035
Label/Sticker: 3008052 / IL-604040
- Technology: UHF
- Frequency: UHF Global 860-960 MHz
- Product Type: Inlays and Tags
- Chip: Impinj Monza M730
- EPC memory: 128 bits
- Material: Dry Inlay, Wet Inlay, Label / Sticker
- Mounting: Non Metal, Glass, Plastic, Wood
- ISO: ISO/IEC 18000-63, EPC Gen2 V2
- Operating temperature: -40 °C to 85 °C / -40 °F to 185 °F
- Size: 45mm x 18mm – 1.77in x 0.71in
